| Power (W/m) | 20.5 |
|---|---|
| Color | RGB |
| Beam Angle | 120˚ |
| Luminaire Lumen Output (lm/m) | R: 91, G: 202, B: 36 |
| IP Rating | IP67 |
| Minimum Bending Radius (cm) | 10 |
| Maximum Length (m) | 8 |
| Cutting pitch (mm) | 71.4 |
| Pixel/m | 14 |
| Voltage (V) | DC24V |
| Ambient Temperature | -40˚C … +65˚C |
| Dimming Options | SPI |
Excellent thermal dissipation encapsulated with high performance grade silicone material with operating temperature up to maximum ta 65°C
Engineered for UV and corrosion resistance, and compliant with the UL 94 V-0 flammability standard
Seamless with no dark spot even at the terminals
Lifetime: 50,000 hours
Direct Artnet-to-SPI interlace; 3072 channels per SPI output line; synchronized Artnet data through ArtSync
Linear daisy-chain of Artnet-to-SPI interfaces of up to 36 controllers per line
Maximum operational frame rate: 48fps
Up to 144m of Contour Light daisy-chained data lines per controller
Up to 50m input shield twisted pair data cable from controller to Contour Light
Design Registration (30202501104Q) – Singapore Registered Designs Act
